1Tenth SOA and 4 Link for SCX10 III Straight Axles is manufactured from Nylon 12 using selective laser sintering.
We alllll know 4 link is superior unless you're going for that scale look. This SOA uses the existing 3 link mount for a brace, cups the truss, and secures in 2 other spots. The top diff mount screw and a through truss brace ensure the servo mount stays put.
Does NOT fit the AR45P on the AR45S straight axle
You have the option of center triangulated or slightly spread upper links. Center Triangulated can be difficult depending on your drivetrain.
I got it as low as possible without the drag link and tie rod contacting. If you want it lower check out the LowLife.
MATERIAL & CONSTRUCTION
Material: PA12
Manufacturing: SLS additive
Finish: Flat semi granular
Weight: ~18g
Dimensions
L-56mm
W-24mm
H-41mm
All hardware to mount on the axle included.
Not intended for a stock chassis but has been done. Easy setup on custom / flat rail chassis usually.
